EARLY WARNING

Composite or individual analysis of the key fault gases dissolved in power transformer oil for early warning indication and initial fault classification.

The HYDROCAL 1001+ is a permanently-installed composite gas-in-oil sensor for the analysis of six dissolved key fault gases such as Hydrogen (H2), Carbon Monoxide (CO), Methane (CH4), Acethylene (C2H2), Ethylene (C2H4), and Ethane (C2H6). To detect an even wider range of potential transformer faults, the HYDROCAL 1001+ analyses additionally the content of Moisture (H2O) in the transformer oil.

The HYDROCAL 1003 is an online monitoring system permanently mounted on the transformer. It measures continuously Moisture in Oil (H2O) and the most important faults gases Hydrogen (H2) and Carbon Monoxide (CO).

HYDROCAL 1003

The HYDROCAL 1003 is an online monitoring system permanently mounted on the transformer. It measures continuously Moisture in Oil (H2O) and the most important faults gases Hydrogen (H2) and Carbon Monoxide (CO).

INTENSIVE CARE

Permanently installed online DGA (Dissolved Gas Analysis) devices for the individual analysis of multiple gases and detailed fault classification.

The HYDROCAL 1005 is a permanently-installed multi-gas-in-oil analysis system with transformer monitoring functions. It allows for the individual measurement of Moisture in Oil (H2O) and the key gases Hydrogen (H2), Carbon Monoxide (CO), Acetylene (C2H2) and  Ethylene (C2H4) dissolved in transformer oil.

The HYDROCAL 1008 is a permanently-installed multi-gas-in-oil analysis system with transformer monitoring functions. It allows for the individual measurement of Moisture in Oil (H2O) and the key gases Hydrogen (H2), Carbon Monoxide (CO), Carbon Dioxide (CO2), Methane (CH4), Acetylene (C2H2), Ethylene (C2H4) and  Ethane (C2H6) dissolved in transformer oil.

The HYDROCAL 1009 is a permanently installed multi-gas-in-oil analysis system with transformer monitoring functions. It individually measures, Moisture in Oil (H2O) and the key gases Hydrogen (H2), Carbon Monoxide (CO), Carbon Dioxide (CO2), Methane (CH4), Acetylene (C2H2), Ethylene (C2H4), Ethane (C2H6) and Oxygen (O2) dissolved in transformer oil.

The HYDROCAL 1005 Offshore is an online monitoring system permanently mounted on the transformer and is special designed for Offshore Wind Power Applications. It allows for the  individual measurement of Moisture in Oil (H2O) and the key gases Hydrogen (H2), Carbon Monoxide (CO), Acetylene (C2H2) and  Ethylene (C2H4) dissolved in transformer oil.

The HYDROCAL 1008 Offshore is an online monitoring system permanently mounted on the transformer and is special designed for Offshore Wind Power Applications. It allows for the  individual measurement of Moisture in Oil (H2O) and the key gases Hydrogen (H2), Carbon Monoxide (CO), Carbon Dioxide (CO2), Methane (CH4), Acetylene (C2H2), Ethylene (C2H4) and  Ethane (C2H6) dissolved in transformer oil.

The HYDROCAL 1009 Offshore is a permanently installed multi-gas-in-oil analysis system with transformer monitoring functions. It individually measures, Moisture in Oil (H2O) and the key gases Hydrogen (H2), Carbon Monoxide (CO), Carbon Dioxide (CO2), Methane (CH4), Acetylene (C2H2), Ethylene (C2H4), Ethane (C2H6) and Oxygen (O2) dissolved in transformer oil.

HYDROCAL GenX

The new HYDROCAL genX product family is the first truly maintenance-free multigas online DGA (Dissolved Gas Analysis) solution combining proven near infrared (NIR) measuring technology with vacuum protected membrane extraction.

Truly maintenance-free multigas online DGA solution combining proven near infrared (NIR) measuring technology with vacuum protected membrane extraction.

ACCESSORIES

The HYDROCAL MS-7, is an extension package to MTE’s HYDROCAL product line. With this solution MTE addresses the issue that thermal conditioning is one of the most important means to detect transformer problems and to avoid transformer outages.

The Bushing Monitor ZVCM-1001, which is an extension package to MTE’s HYDROCAL product line, is a permanently installed on-line bushing monitoring system. It continuously measures up to six leakage currents, tests the power factor and capacitance values. By providing this additional value, MTE answers the fact that bushing failures are considered as one of the major causes for transformer outages.

Hydrosoft is a program compatible with MS Windows for controllingthe eintire MTE HYDROCAL product line and reading out all kind of relevant data.
